Double-coated Tape D9605

Nitto D9605 is a double-coated tapes with a polyester carrier coated with an aggressive acrylic adhesive used for mounting of different types of plastics.

Download

Datasheet

SDS

Datasheet

NBE_D9605_ENG

SDS

The information contained herein is based on all the documentation, information and data that can be obtained as of the date issued.

However, Nitto Denko Co., provides no warranties or guarantees, express or implied, regarding the accuracy or completeness of the information on contained amount, physical or/and chemical properties, and hazards or/and harm mentioned herein.

As for SDS of products categorized as "Article", Nitto Denko Co., voluntarily creates and releases the SDS for the particular products which frequently receive inquiries.

SDS_NBE_D9605_ENG

Features
Structure
Properties
Applications

Features

High adhesion on different substrates & rough surfaces
High temperature resistance
High holding power
Easy processing
Bobbin shape
RoHS compliant (2011/65/EC, 2015/863)

Structure

Modified acrylic adhesive
Polyester carrier
Modified acrylic adhesive
Release liner

Properties

Adhesive type	Pressure sensitive modified acrylic adhesive
Tape thickness	0.220 mm
Release liner	Siliconised havana paper (90 g/m²)
Carrier type	Ppolyester (0.050 mm)
Adhesion value	2000 cN/20mm
Release value	30 cN/50mm
Static shear	1 mm/3h

Applications

Nitto D9605 is used for mounting decorative profi les in furniture industry (trim mounting), cable ducts. Available in bobbin shapes designed for continuous application process.

Suitable for mounting price information holders and plastic parts in sign & nameplate markets for marketing devices (Point Of Sales).
