Double-coated Tape 61390

Nitto 61390 is a differential pressure sensitive adhesive double-coated tape used for
reworkable mounting applications on various substrates.

Download

Features

  • Differential adhesive system
  • Open side adheres to a variety of substrates
  • Closed side is clean removable and easy to reposition
  • RoHS compliant

Structure

  1. Acrylic adhesive
  2. Polyester carrier
  3. Acrylic adhesive
  4. Release liner

Properties

Adhesive typeS1: modified acrylic adhesive, S2: pure acrylic adhesive
Tape thickness0,090 mm
Release linerSiliconised white paper
Carrier typeTransparent polyester
Adhesion value1500 cN/20mm
Release value15 cN/50mm
Static shear0,5 mm/3h

Applications

Nitto 61390 is used for temporary bonding of flexible substrates such as foams, cork
and films, requiring an easy removal without leaving adhesive residue.
