Nitto double coated tape D5052 and D5052H consist of a non-woven tissue carrier coated with a pressure sensitive modified acrylic adhesive.
D5052 and D5052H are intended to be used on different foams where high adhesion levels are required.
 |
| Typical value* | Test Method | |
|---|---|---|
| Tape thickness** | 0.140 mm | EN 1942 |
| Adhesive type | Modified acrylic | n/a |
| Release liner type |
D5052: Siliconized white paper (120g/m²) D5052H: Siliconized Havana paper (90g/m²) |
n/a |
| Carrier type | Non-woven | n/a |
| Adhesion to BA steel | 2000 cN/20mm | EN 1939/ ISO 29862 |
| Adhesion to ABS | 1600 cN/20mm | EN 1939/ ISO 29862 |
| Adhesion to PP | 1200 cN/20mm | EN 1939/ ISO 29862 |
| Static shear | 1 mm/3h | EN 1943 |
| Saft test | 100°C | +0.5°C/min, 20x15mm, 200g |
Nitto D5052 and D5052H are designed for foam lamination applications requiring high adhesion strength suitable for bonding to a wide range of substrates, including PUR foams, impregnated foams, textiles, fabrics, cork, and felts, making them ideal for demanding industrial applications where reliable adhesion is critical.
