Double-coated Tape D9600

Nitto D9600 is a double-coated tape with a flame retardant pressure sensitive modified acrylic adhesive and a PET carrier, intended for use as a general mounting tape where flame retardancy is required.

Download

Datasheet

SDS

Datasheet

NBE_D9600_ENG

SDS

The information contained herein is based on all the documentation, information and data that can be obtained as of the date issued.

However, Nitto Denko Co., provides no warranties or guarantees, express or implied, regarding the accuracy or completeness of the information on contained amount, physical or/and chemical properties, and hazards or/and harm mentioned herein.

As for SDS of products categorized as "Article", Nitto Denko Co., voluntarily creates and releases the SDS for the particular products which frequently receive inquiries.

SDS_NBE_D9600_ENG

Features
Structure
Properties
Applications

Features

Flame retardant
Excellent holding power
High adhesion
Adheres to a wide variety of substrates
Easy processability
RoHS compliant

Structure

Acrylic adhesive
Polyester carrier
Acrylic adhesive
Release liner

Properties

Adhesive type	Flame retardant modified acrylic adhesive
Tape thickness	0,100 mm
Release liner	Siliconised white PE coated paper
Carrier type	Transparent polyester
Adhesion value	1500 cN/20mm
Release value	20 cN/50mm
Static shear	1,0 mm/3h

Applications

Nitto D9600 is designed to make flame retardant materials self-adhesive such as decorative laminates and foams for applications in automotive, building and construction, shipbuilding and aerospace industries.
Flame retardancy must be evaluated in combination with the material on which it will be used.
