Double-coated Tape D5052

Nitto double coated tape D5052 consists of a non-woven carrier coated with a
pressure sensitive modified acrylic adhesive, intended for use on different foams where high adhesion levels are required.

Download

Datasheet

SDS

Datasheet

NBE_D5052(H)_ENG

SDS

The information contained herein is based on all the documentation, information and data that can be obtained as of the date issued.

However, Nitto Denko Co., provides no warranties or guarantees, express or implied, regarding the accuracy or completeness of the information on contained amount, physical or/and chemical properties, and hazards or/and harm mentioned herein.

As for SDS of products categorized as "Article", Nitto Denko Co., voluntarily creates and releases the SDS for the particular products which frequently receive inquiries.

SDS_NBE_D5052_ENG

Features
Structure
Properties
Applications

Features

High initial adhesion
Polyvalent on different foams
RoHS compliant

Structure

Acrylic adhesive
Non-woven tissue
Acrylic adhesive
Release liner

Properties

Adhesive type	Pressure sensitive modified acrylic adhesive
Tape thickness	0,145 mm
Release liner	Siliconised white paper
Carrier type	Non-woven tissue
Adhesion value	2000 cN/20mm
Release value	40 cN/50mm
Static shear	1 mm/2h

Applications

This tape has been designed for lamination to a variety of PUR foams, impregnated foams and many other substrates such as textiles, fabrics, cork and felts.
